| Model NO. | AC87 |
| Features |
| ◆ Easy to install and use |
| ◆ Clear and smooth video browsing; intelligent transmission giving full play to capabilities of the network |
| ◆ Online firmware upgrade, and synchronous updating of the functions and experience |
| ◆ Two-way voice intercom supported; echo eliminated; noise suppressed |
| ◆ Compatible with Android; remote real-time monitoring supported with the IOS intelligent terminal |
| ◆ 2-megapixel high resolution (1920X1080) for clear picture quality |
| ◆ Lighting for infrared night vision (with a night vision distance of 7m); 24h around-the-clock monitoring; IR-CUT switching; free of color cast in the daytime; clearer night vision |
| ◆ The built-in rechargeable lithium battery with long battery life functions for up to 6 months under normal circumstances and can stand by for 12 months |
| ◆ 2.4G Wi-Fi supported (IEEE802.11b/g/n) |
| ◆ Cloud storage, Micro SD card (up to 128GB) and mobile phone video recording supported |
| ◆ QR code intelligent connection and network allocation supported |
| ◆ Supporting human contour detection, activity zone, intelligent push and pet snapshot,Package inspection (value added service required) |
| ◆ IP65 Easy installation: support 1 / 4 universal screw bracket |
| Specifications |
| Main Processor |
| SOC | T31ZL |
| Image Sensor |
| Sensor | 1/2.9" color CMOS Sensor |
| Lens | M12, f: 3.3mm, F2.0, 2-megapixel |
| Visual angle | H (horizontal) 95 degrees; V (vertical) 55 degrees; D (diagonal) 110 degrees |
| Minimum Illumination | 0.01 Lux |
| Audio |
| Input/Output | Two-way voice intercom available (built-in Microphone and speaker) |
| Audio Compressing Method | AAC |
| Video |
| Video Compressing Method | H.264/H.265 |
| Lighting Frequency | 50Hz, 60Hz |
| Image Frame Rate | 15 fps |
| Maximum Image Resolution | 1920*1080P |
| Light Source for Night Vision | IRCUT double optical filter automatic switching, and 8 infrared lights (850nm wavelength)Irradiation distance: 7M |
| Network |
| Wireless Network | 2.4G Wi-Fi (IEEE802.11b/g/n), built-in antenna |
| Protocols Supported | TCP/IP, UDP/IP, DHCP, RTMP, MUTP |
| IP Address Supported | Dynamic IP address supported |
| AI |
| Intelligent Features | Human contour detection, activity zone,intelligent push, pet snapshot,Package inspection |
| Alarm Notification |
| Alarm Methods | Alarm push by mobile APP and alarm sound |
| Wake-up |
| Wake-up Method | PIR body induction wake-up, and remote positive wake-up |
| Video Recording |
| Recording Method | Alarm triggered recording, and manual recording |
| Video Storage | Cloud storage, local Micro SD card, and mobile phone memory |
| Indicator Lamps |
| LED Indicator | RGB tri-color lamp indicating the status of power/network signal/functionality |
| Battery |
| Capacity | 5200mAh/6700mAh（Optional ） |
| Removability | Unremovable |
| Battery Life | 6 months (provided that 20 10s videos are recorded per day) |
| Standby Time | 1 year |
| Charging Voltage | DV 5V+-5%/1.5A |
| Charge Time | Within 10 hours |
| Protection Method | IP65 is dustproof and waterproof; over-current/over-discharge/over-charge/short circuit/charging protection at high & low temperatures |
| Power Consumption |
| Standby Power Consumption | 1.68mW（4V 0.42mA） |
| Power Consumption of Daytime Operation | 0.88W（4V 220mA） |
| Power Consumption of Operation at Night | 2.20W（4V 550mA） |
| Interface |
| Power Supply | 1 Micro USB interface |
| SD Card | 1 Micro SD card (up to 128GB supported) |
| Keys | 1 reboot key and 1 on/off key |
| Installation Method |
| Installation Method | Bottom 1/4 universal screw hole |
| Environment |
| Dustproof and waterproof | IP65 |
| Operating Environment | -10° ~ 45°C /10% ~ 80% (no condensation) |
| Storage Environment | -20°C ~ 60° /0% ~ 90% (no condensation) |
| Specifications |
| Size (LxWxH) | 89mm*58mm*59mm(without bracket) |
| Material + Process | ABS+PC |
| Color | White |
| Certification |
| Certificate | CE, FCC, RoHS, WEEE, MSDS, UN38.3, UL62368, BattG |
