| Model NO. | AC85 |
| Features |
| ◆ Easy to install and use |
| ◆ Clear and smooth video browsing; intelligent transmission giving full play to capabilities of the network |
| ◆ Online firmware upgrade, and synchronous updating of the functions and experience |
| ◆ Two-way voice intercom supported; echo eliminated; noise suppressed |
| ◆ Compatible with Android; remote real-time monitoring supported with the IOS intelligent terminal |
| ◆ 2-megapixel high resolution (1920X1080) for clear picture quality |
| ◆ Lighting for infrared night vision (with a night vision distance of 7m); 24h around-the-clock monitoring; IR-CUT switching; free of color cast in the daytime; clearer night vision |
| ◆ Intelligent push to filter out useless information |
| ◆ 2.4G Wi-Fi supported (IEEE802.11b/g/n) |
| ◆ Intelligent storage algorithm, small space can accommodate more content, support Micro SD card, cloud storage |
| ◆ QR code intelligent connection and network allocation supported |
| ◆ Supporting human contour detection, activity zone, intelligent push and pet snapshot |
| ◆Small and exquisite appearance, various colors |
| Specifications |
| Main Processor |
| SOC | ARM |
| Image Sensor |
| Sensor | 1/3" color CMOS sensor |
| Lens | M12, f: 3.6mm, F2.0, 2-megapixel |
| Visual angle | H (horizontal) 85 degrees; V (vertical) 48 degrees; D (diagonal) 100 degrees |
| Minimum illumination | 0.01Lux |
| Audio |
| Input/Output | Two-way voice intercom available (built-in Microphone and speaker) |
| Audio compression method | AAC |
| Video |
| Video compression method | H.264/H.265 |
| Lighting frequency | 50Hz, 60Hz |
| Image frame rate | 15fps |
| Maximum Image Resolution | 1920*1080P |
| Light Source for Night Vision | IRCUT double filter automatic switching, 6 infrared lamps (850nm wavelength), irradiation distance:5 meters |
| Network |
| Wireless Network | 2.4G Wi-Fi (IEEE802.11b/g/n), built-in antenna |
| Protocols Supported | TCP/IP, UDP/IP, DHCP, RTMP, MUTP |
| IP Address Supported | Dynamic IP address supported |
| AI |
| Intelligent function | Intelligent push, pet snapshot, human contour detection, package detection,motion tracking |
| Alarm |
| Alarm detection | Motion Detection |
| Alarm linkage | Support video recording, sound alarm |
| Alarm notification | Alarm push by mobile APP |
| PTZ |
| PTZ rotation angle | H (horizontal) 0° ~ 355°; V (vertical) -20° ~ 90° |
| Interface |
| Power Supply | 1 Micro USB interface, DC 5V/1A |
| SD card | 1 Micro SD card (up to 128GB) |
| Keys | 1 function key |
| Other |
| Adjustable lens | Not adjustable |
| LED indication | Monochrome white light (power/network signal/function indicator) |
| Video storage method | Micro SD card (up to 128GB) local storage, cloud storage |
| Install method | Ceiling or wall hanging |
| Environment |
| Dustproof and waterproof | no |
| Operating environment | -10° ~ 45°C /10% ~ 80% (no condensation) |
| Storage environment | -20°C ~ 60° /0% ~ 90% (no condensation) |
| Color |
| Appearance color | White |
| Specification |
| Dimensions (L*W*H) | 75mm*75mm*110mm |
| Net Weight of Bare Machine | Approx. 190g |
| Certification |
| Certificate | CE, FCC, RoHS |
