Model NO. | AC31 |
Package |
Camera | 1pcs |
Adaptor | 1xDC 5V 1A |
Camera |
Image Sensor | 1/2.9"CMOS sensor |
Resolution | 2MP 1080P |
Effective Pixels | 1920(H)*1080(V) |
Compression | H.265/20FPS |
Electronic Shutter Time | Auto(1 / 10s~1 / 100000s) |
S/N Ratio | 39dB |
Scanning System | Progressive |
Video Output | Wireless network |
Reset Button | Yes |
PTZ |
Horizontal Rotation Range | 0~355° |
Tilt Rotation Range | 0~90° ( Manual ) |
LENS Type |
Focus Length | 3.6mm F2.4 |
Focus Control | Fixed |
Lens Type | Fixed |
Pixels | 4M Pixels |
Night Vision |
Infrared LED | 14µ x 6PCS |
Infrared Distance | 5~10M |
IR Status | CDS Auto Control |
IR Power On | Auto Control |
Network |
Ethernet | RJ-45 (10/100Base-T) |
Protocol | TCP/IP、UDP、RTSP、HTTP、DDNS、DHCP、FTP、NTP |
ONVIF | / |
P2P | Support |
POE | / |
Main Stream 1 | 1920*1080@20fps |
Main Stream 2 | / |
Main Stream 3 | / |
Sub Stream 1 | 640*480@20fps |
Sub Stream 2 | / |
Sub Stream 3 | / |
Tri Stream | / |
IE Brower | / |
Smart Phone | support |
Wireless |
Antenna | 5dbi |
Hotspot | Support |
Wi-Fi | Wi-Fi(IEEE802.11b/g/n) |
WIFI Range | No obstacles 270m Max. |
Camera Features |
Day/Night | Color/ B&W (IR-CUT ) |
Minimun Illumination | 0.01 Lux |
Image Config | YES |
Corridor Pattern | / |
ROI | / |
Defog Mode | / |
BLC | / |
HDR | / |
3DNR | Support |
DWDR | Support |
Motion Detection | Support |
Privacy Masking | / |
Recording Mode | SDcard / Cloud storage (optional) |
Language | Chinese、English |
Interface |
Audio | 2-Way Audio |
Alarm | Motion Detection |
SD Card Slot | Support Max 128G |
General |
Housing | plastic |
Bracket | Support |
IR Cut Filter | YES |
Operation Temperature | -10℃ ~ +50℃ RH75% Max |
Storage Temperature | -20℃ ~ +60℃ RH75% Max |
Size | 112(W)x106(H)mm |
